Highlights
This full-composite frame is engineered for 135mm of rear travel and 150mm up front. The Maestro rear suspension has a two-stage adjustable Advanced Forged Composite rocker arm with a trunnion-mount shock. A flip chip lets you choose either low or high frame geometry settings, which adjusts the headtube and seattube angle, along with the bottom bracket drop, to fine tune handling for your riding style and terrain.
-
Sizes
S, M, L, XL
-
Colors
Phantom Green / Dark Iridescent / Chrome
-
Frame
Advanced-Grade Composite front and rear triangles, 135mm Maestro suspension, flip chip, 12x148mm thru-axle
-
Fork
Marzocchi Z2, 150mm, Rail damper, Boost 15x110 Kabolt, 44mm offset, custom tuned for Giant
-
Shock
Fox Float DPS Performance, 185/55, custom tuned for Giant
-
Handlebar
Giant Contact TR35, 780x35mm, 20mm rise
-
Grips
Giant Tactal Pro Single S:120mm, M:120mm, L:130mm, XL:130mm
-
Stem
Giant Contact SL 35 S:40mm, M:40mm, L:50mm, XL:50mm
-
Seatpost
Giant Contact Switch dropper, remote S: 125mm travel / 30.9 x 395mm M: 150mm travel / 30.9 x 440mm L: 170mm travel / 30.9 x 450mm XL: 170mm travel / 30.9 x 450mm
-
Saddle
Giant Romero SL
-
Pedals
N/A
-
Shifters
SRAM SX Eagle, 1x12
-
Front Derailleur
N/A
-
Rear Derailleur
SRAM SX Eagle
-
Brakes
Tektro HD M745
-
Brake Levers
Tektro HD M745
-
Cassette
SRAM SX, 11x50
-
Chain
SRAM SX Eagle
-
Crankset
SRAM SX, 30t S:165mm, M:170mm, L:170mm, XL:170mm
-
Bottom Bracket
SRAM DUB, press fit
-
Rims
Giant TR 1 29 WheelSystem
-
Hubs
Giant TR 1 29 WheelSystem
-
Spokes
Giant TR 1 29 WheelSystem
-
Tires
[F] Maxxis Minion DHF 29x2.5 WT, 3C MaxxTerra, EXO, TR [R] Maxxis Dissector 29x2.4 WT, 60 TPI, 3C Max Terra, EXO, TR
-
Extras
tubeless prepared, 2.5" max tire size, 34t max chainring size, 3M tailgate protector
-
Weight
13.94 kg (30 lb 10oz) - Size (XL)
